539DME Special Effect Operations
Chapter 11 DME Operations
Texture deformations
You can change the texture pattern, position, and size, and use the repetition
function.
The following figure shows examples of a texture pattern repeated in the X and
Y directions.
Setting lights
Light source types
The following type of light sources are available (see figure).
Parallel: Parallel light source
Point: Point light source. As the light source is placed further away, the
illuminated range becomes wider and the light become weaker.
Line: Line light source
Whole: Non-directional light source which illuminates the whole image.
Original image
Repetition in X
direction
Repetition in Y
direction
Repetition in X and Y
directions
Light source
Light source
Light source
Parallel Point Line Whole
