Correspondence
between API registers
and API
low-layer driver functi
ons
UM1940
1358
/1371
DocID028236 Re
v 2
Register
Field
Function
LL_TIM_EnableIT_CC4
LL_TIM_IsEnabledIT_CC4
COMDE
LL_TIM_DisableDMAReq_COM
LL_TIM_EnableDMAReq_COM
LL_TIM_IsEnabledDMAReq_COM
COMIE
LL_TIM_DisableIT_COM
LL_TIM_EnableIT_COM
LL_TIM_IsEnabledIT_COM
TDE
LL_TIM_DisableDMAReq_TRIG
LL_TIM_EnableDMAReq_TRIG
LL_TIM_IsEnabledDMAReq_TRIG
TIE
LL_TIM_DisableIT_TRIG
LL_TIM_EnableIT_TRIG
LL_TIM_IsEnabledIT_TRIG
UDE
LL_TIM_DisableDMAReq_UPDATE
LL_TIM_EnableDMAReq_UPDATE
LL_TIM_IsEnabledDMAReq_UPDATE
UIE
LL_TIM_DisableIT_UPDATE
LL_TIM_EnableIT_UPDATE
LL_TIM_IsEnabledIT_UPDATE
EGR
BG
LL_TIM_GenerateEvent_BRK
CC1G
LL_TIM_GenerateEvent_CC1
CC2G
LL_TIM_GenerateEvent_CC2
CC3G
LL_TIM_GenerateEvent_CC3
CC4G
LL_TIM_GenerateEvent_CC4
COMG
LL_TIM_GenerateEvent_COM
TG
LL_TIM_GenerateEvent_TRIG
UG
LL_TIM_GenerateEvent_UPDATE
PSC
PSC
LL_TIM_GetPrescaler
LL_TIM_SetPrescaler
RCR
REP
LL_TIM_GetRepetitionCounter
LL_TIM_SetRepetitionCounter
SMCR
ECE
LL_TIM_DisableExternalClock
LL_TIM_EnableExternalClock
LL_TIM_IsEnabledExternalClock
LL_TIM_SetClockSource
1357
1359
