Operation 5
Handling the battery
Lifting accessory
DANGER
Risk of accident!
The battery could fall from the lifting accessory
or the lifting accessory could tip over or become
damaged. If this happens, there is a risk to life.
The battery must only be removed when the truck
is on level, smooth ground with sufficient load
capacity. The load capacity of the lifting accessory
used (see operating instructions or nameplate)
must at least match the battery weight (see battery
identification plate).
– Ensure the load capacity of the lifting accessory.
– Remove the battery on suitable ground.
Battery removal from trucks with an internal
roller channel can be carried out with the
following lifting accessories:
• Lift truck including external roller channel
(variant)
The battery can be removed from trucks with
a bridge (variant) using the following lifting
accessories:
• Crane
NOTE
The removal of batteries from trucks without
their own devices must be carried out by the
authorised service centre.
Battery weight and dimensions
DANGER
Risk of tipping due to change in battery weight!
The battery weight and dimensions affect the sta-
bility of the truck. When replacing the battery, the
weight ratios must not be changed. The battery
weight must remain within the weight range speci-
fied on the nameplate.
– Do not remove or change the position of ballast
weights.
– Note the battery weight.
55
048011501 EN - 12/2015 253
