5 Operation
Handling the battery
5060_003-153
6
7
8
Transporting and setting down the
battery
DANGER
WARNING
If the safety lever (7) is not applied in
front of the battery (8), the battery can
roll off the external roller channel (6),
creating a risk of crushing!
– Ensure that the safety lever (7) is
fully applied in front of the battery
(8).
WARNING
Excessive speed, sharp turns and heavy braking
can cause the hand pallet truck and battery to tip
over, creating a risk of injury!
– Take special care when transporting the battery.
– Keep the transport speed low, steer carefully
and brake gently.
– Do not use the methods described above to
transport the battery over long distances.
– Transport the battery to the intended
storage space.
CAUTION
If the battery support is not sufficiently strong, it
can be damaged or destroyed by the weight of the
battery.
– The battery must be stored on a suitable beam
support or on suitable racking.
– The battery must not be stored on a wooden
beam or the like.
– Set down the battery.
Installing the battery
CAUTION
If when the battery is being installed the battery
hood or the battery door are not fully open, or the
interlock is folded up or pulled out, or if there are
objects in the truck’s battery compartment, consi-
derable damage will be done to these components
during installation of the battery.
– Open the battery hood.
– Open the battery door.
– Remove all objects from the battery compart-
ment.
27
6 55048011501 EN - 12/2015
