7 Technical data
VDI datasheet: RX50-15 and RX50-16
Wheels, chassis frame
Model
RX50-15 RX50-16
Type number
5065 5066
Tyres
Superelastic Superelastic
Front tyre size
180/70-8 180/70-8
Rear tyre size
180/70-8 180/70-8
Number of front wheels (x =
driven)
22
Number of rear wheels (x =
driven)
1x 1x
Front track width
b
10
(mm)
840 840
Rear track width
b
11
(mm)
——
.
Basic dimensions
Model
RX50-15 RX50-16
Type number
5065 5066
Tilt of lift mast/fork carriage, forwards α (degrees)
33
Tilt of lift mast/fork carriage, backwards β (degrees)
55
Height with lift mast retracted h
1
(mm)
2160 2160
Free lift
h
2
(mm)
150 150
Lift
3
h
3
(mm)
3230 3230
Height with lift mast extended h
4
(mm)
3805 3805
Height to top of overhead guard (cab) h
6
(mm)
2050 2050
Seat height (in relation to SIP)
h
7
(mm)
953 953
Coupling height h
10
(mm)
——
Total length
l
1
(mm)
2575 2580
Length including fork back l
2
(mm)
1775 1780
Total width
b
1
(mm)
990 990
Fork arm thickness
s (mm)
40 40
Fork arm width
e (mm)
80 80
Fork arm length l (mm)
800 800
Fork carriage according to ISO 2328,
class/form A, B
ISO II/A ISO II/A
3
The specified lift takes into account the tyre deflection and the tolerances ofthetyrediameter.
34
4 55048011501 EN - 12/2015
