Technical data 7
VDI datasheet: RX50-15 and RX50-16
Model RX50-15 RX50-16
Type number
5065 5066
Fork carriage width b
3
(mm)
980 980
Ground clearance with load under lift mast
m
1
(mm)
90 90
Ground clearance at centre of wheelbase
m
2
(mm)
90 90
Aisle width for pallet 1000 x 1200 cross-
wise
A
st
(mm)
3104 3109
Aisle width for pallet 800 x 1200 longitudi-
nal
A
st
(mm)
3226 3231
Turning radius W
a
(mm)
1445 1445
Smallest pivot point distance
b
13
(mm)
——
.
Performance data
Model
RX50-15 RX50-16
Type number
5065 5066
Driving speed with load
km/h 12.0 12.0
Driving speed without load
km/h 12.5 12.5
Lifting speed w
ith load
m/s 0.32 0.30
Lifting speed
without load
m/s 0.54 0.54
Lowering speed with load
m/s 0.54 0.54
Lowering speed without load
m/s 0.60 0.60
Pulling for
ce with load
N 1280 1240
Pulling force without load
N 1670 1670
Max. pulli
ng force without load
N 3770 3470
Max. pull
ing force without load
N 7150 7150
Climbin
g capability with load
%4.04.0
Climbing capability without load
%
8.0
7.5
Max. climbing capability with load
% 16.0 15.0
Max. climbing capability without load
% 25.0 25.0
Acceleration time with load
s
5.5 5.6
Acceleration time without load
s
4.9 5.0
Service brake
Hydraulic Hydraulic
.
55
048011501 EN - 12/2015 345
