Argument Button
TRIGger Trigger Menu button
FORCetrig Force Trig button
CH1 Channel1 select button
CH2 Channel2 select button
CH3 Channel3 select button
CH4 Channel4 select button
DEFaultsetup Default Setup button
COURse Course button
FUNCtion Function button
ZOOM Zoom button
FINe Fine button
CURsor Cursors button
RUnstop Run/Stop button
SINGleseq Single button
AUTOset Autoset button
SETTO50 Trigger level knob can be pressed to Set Trigger
to 50%
HARDcopy Hardcopy button
RMENU1 Screen top-most side menu button
RMENU2 Screen side menu button
RMENU3 Screen side menu button
RMENU4 Screen side menu button
RMENU5 Screen side menu button
RMENU6 Screen side menu button
RMENU7 Screen bottom-most side menu button
MENUOff Menu On/Off button
GPKNOB Multipurpose knob can be pressed for selection.
HORZPos Horizontal Position knob can be pressed to set
horizontal position to center.
VERTPOS<n> Vertical Position knob can be pressed to set
vertical position to center.
VERTSCALE<n> Vertical Scale knob can be pressed to set trigger
source
Examples
FPANEL:PRESS AUTOSET executes the instrument Autoset function.
F commands
TBS2000 Series Programmer 137
