Examples
CURSOR:HBARS:DELTA? might return :CURSOR:HBARS:DELTA 5.0800E
+00 indicating that the difference between the two cursors is 5.08.
CURSor:HBArs:POSITION<x>
Sets or returns the horizontal bar cursor position relative to ground, which is
expressed in vertical units (usually volts). The cursor is specified by x, which can
be 1 or 2.
Group
Cursor
Syntax
CURSor:HBArs:POSITION<x> <NR3>
CURSor:HBArs:POSITION<x>?
Related commands
CURSor:FUNCtion on page 77
Arguments
<NR3> specifies the horizontal bar cursor position, relative to ground (in volts
when the units are volts and amps when the units are amps), relative to the center
of the screen (in divs when units are divisions), or relative to 1 V RMS (in
decibels when the source is an FFT math waveform), for the waveform specified
by the CURSor:SELect:SOUrce command.
The cursor position is limited to the graticule whenever an attempt is made to
move it outside the graticule.
NOTE. The source determines the measurement units.
Examples
CURSOR:HBARS:POSITION1 25.0E-3 positions Cursor 1 of the horizontal
cursors at 25 mV.
CURSOR:HBARS:POSITION2? might return :CURSOR:HBARS:POSITION2
-64.0000E-03 indicating that Cursor 2 of the horizontal bar cursors is at -64 mV.
C commands
TBS2000 Series Programmer 79
