Horizontal command group
Horizontal commands control the time bases of the instrument. You can set the
position and time per division of both the main and window time bases. You can
substitute SECdiv for SCAle in all appropriate horizontal commands. This
provides program compatibility with previous Tektronix digitizing instruments.
Table 16: Horizontal commands
Command Description
HORizontal? on page 148 Returns all settings for the horizontal
commands.
HORizontal[:MAIn]:SCAle on page 155 Sets or queries the time base horizontal scale.
HORizontal[:MAIn]:SECdiv on page 156 Specifies the horizontal time/div.
HORizontal:TRIGger:POSition on page 159 Same as :HORizontal:POSition.
HORizontal:TRIGger:POSition on page 159 Set or queries the trigger position.
HORizontal[:MAIn][:DELay]:POSition on
page 151
Sets or returns the horizontal position, as
percent of record, that is used when
HORizontal:DELay:MODe is set to OFF.
HORizontal[:MAIn]:DELay:MODe on page 152 The boolean argument type sets delay mode to
on or off.
HORizontal[:MAIn]:DELay:STATe on page 153 Same as HORizontal:DELay:MODe.
HORizontal[:MAIn]:DELay:TIMe on page 154 Specifies the delay time in time units.
HORizontal:DELay:SCAle on page 150 Same as HORizontal:SCAle.
HORizontal:DELay:SECdiv on page 150 Same as HORizontal:SCAle.
HORizontal:RESOlution on page 158 Same as HORizontal:RECOrdlength.
HORizontal:RECOrdlength on page 157 Sets or queries the horizontal record length.
HORizontal:RECOrdlength:Auto on page 158 Sets or queries the record length mode.
HORizontal:ACQLENGTH on page 149 Queries the record length.
HORizontal:PREViewstate on page 157 Returns a boolean to indicate whether the
acquisition system is in the preview state
HORizontal[:MAIn]:SAMPLERate on page 154 Returns the sample rate
HORizontal:MAIn:UNIts[:STRing] on page 156 Queries the horizontal units.
HORizontal:DIVisions on page 151 Queries the number of horizontal divisions.
HORizontal:ROLL on page 159 Query the state of roll mode.
Command groups
20 TBS2000 Series Programmer
