MEASUrement:IMMed:SOUrce2
Sets or queries the secondary source for dual-source immediate measurements.
NOTE. Source2 measurements only apply to phase and delay measurement types,
which require both a target (Source1) and reference (Source2) source.
Group
Measurement
Syntax
MEASUrement:IMMed:SOUrce2 {CH<x> | MATH}
MEASUrement:IMMed:SOURCE2?
Related commands
MEASUrement:IMMed:SOUrce1 on page 175
Arguments
CH<x> specifies the measurement source channel as one of the input channels.
The value of <x> can vary from 1 through 4 depending on instrument model.
MATH specifies the measurement source channel as the math waveform.
Examples
MEASUrement:IMMed:SOUrce2 CH2 sets the CH2 waveform as the delay to
source when making delay measurements.
MEASUrement:IMMed:SOUrce2? might
return :MEASUREMENT:IMMED:SOURCE2 MATH indicating that Math is
the immediate measurement source.
M commands
176 TBS2000 Series Programmer
