CURSor:HBArs:UNIts
Sets or queries the vertical scale units for the selected cursor source waveform.
Group
Cursor
Syntax
CURSor:HBArs:UNIts {BASe|PERcent}
CURSor:HBArs:UNIts?
Arguments
BASe selects the vertical units for the selected waveform.
PERcent selects ratio cursors.
Returns
VOLTS indicates volts from ground as the unit of measure.
DIVS indicates divisions as the unit of measure, with center of screen as
0 divisions and bottom of screen as -4 divisions.
DECIBELS indicates decibels as the unit of measure, relative to a 1 V
rms
sine
wave. (FFT only)
UNKNOWN indicates that Trigger View is active. This also generates event
message 221. (Settings conflict)
AMPS indicates amperes as the unit of measure.
VOLTSSQUARED indicates volts squared (V*V) as the unit of measure.
AMPSSQUARED indicates amperes squared (A*A) as the unit of measure.
VOLTSAMPS indicates voltage times current (V*A) as the unit of measure.
NOTE. Unknown units are represented by "" in the instrument readouts.
C commands
80 TBS2000 Series Programmer
