Related commands
WFMOutpre:XUNit? on page 263
Arguments
<Qstring> contains a maximum of three alpha characters that represent the
horizontal unit of measure for the incoming waveform.
Examples
WFMINPRE:XUNIT "HZ" specifies that the horizontal units for the incoming
waveform are hertz.
WFMINPRE:XUNIT? might return :WFMINPRE:XUNIT "s" indicating that the
horizontal units for the incoming waveform are seconds.
WFMInpre:XZEro
Sets or queries the position value, in XUNits, of the first sample of the incoming
waveform, relative to the trigger.
The instrument sets WFMPre:XZEro to zero when:
â–
The display mode is set to XY.
â–
The DATa:SOUrce is set to MATH FFT when the waveform is acquired.
NOTE. The instrument uses XZEro when calculating cursor readouts.
Group
Waveform
Syntax
WFMPre:XZEro <NR3>
WFMPre:XZEro?
Related commands
WFMInpre:XINcr on page 252, WFMInpre:BYT_Nr on page 250,
WFMOutpre:XZEro? on page 264
W commands
TBS2000 Series Programmer 253
