Table 11: Cursor commands
Command Description
CURSor? on page 76 Returns current cursor settings.
CURSor:FUNCtion on page 77 Selects and displays the instrument cursor type.
CURSor:HBArs? on page 78 Returns the settings for the instrument horizontal
bar cursors.
CURSor:HBArs:DELTa? on page 78 Returns the difference (in vertical units) between
the two horizontal bar cursors in the instrument
display.
CURSor:HBArs:POSITION<x> on page 79 Positions a horizontal bar cursor.
CURSor:HBArs:UNIts on page 80 Returns the vertical scale units for the selected
cursor source waveform.
CURSor:HBArs:USE on page 81 Sets the horizontal bar cursor measurement
scale.
CURSor:MODe on page 82 Sets or returns whether cursors move in unison
or separately.
CURSor:VBArs? on page 83 Returns the current vertical bar cursor horizontal
position and units settings.
CURSor:VBArs:ALTERNATE<x>? on page 83 Returns the alternate readout for the waveform
(Vbar) cursors.
CURSor:VBArs:DELTa? on page 84 Returns the time or frequency difference
between the two vertical bar cursors.
CURSor:VBArs:HPOS<x>? on page 84 Returns the horizontal value of the specified
vertical bar ticks for cursor <x>
CURSor:VBArs:POSITION<x> on page 85 Sets or returns the vbar cursor<x> horizontal
position
CURSor:VBArs:UNIts on page 86 Sets or queries the units for the vertical bar
cursors.
CURSor:VBArs:VDELTa? on page 87 Returns the vertical (amplitude) difference
between the two vertical bar cursors.
CURSor:VBArs:VDELTa? on page 87 Returns the difference between the cursors X
radius and the cursor Y radius.
Command groups
16 TBS2000 Series Programmer
