Tektronix TBS2000 Series User Manual

Command Description
CH<x>:PRObe:GAIN on page 69 Sets or queries the gain factor of the probe that
is attached to the specified channel.
CH<x>:PRObe:ID? on page 70 Returns the type and serial number of the probe
that is attached to the specified channel.
CH<x>:PRObe:ID:SERnumber? on page 70 Returns the serial number of the probe that is
attached to the specified channel.
CH<x>:PRObe:ID:TYPE? on page 71 Returns the type of probe that is attached to the
specified channel.
CH<x>:PRObe:SIGnal on page 71 Sets or queries the input bypass setting of the
TekVPI probe attached to the specified channel.
CH<x>:PRObe:UNIts? on page 72 Returns the units of measure of the probe that is
attached to the specified channel.
CH<x>:SCAle on page 72 Sets or queries the vertical scale of the specified
instrument channel.
CH<x>:VOLts on page 73 Sets or queries the vertical sensitivity of the
specified channel.
CH<x>:YUNit on page 74 Sets or queries the units of the specified
channel.
REF<x>? on page 200 Returns reference waveform data for the
specified channel.
REF<x>:DATE? on page 200 Returns the date that the reference waveform
was stored.
REF<x>:TIMe? on page 201 Returns the time that the reference waveform
was stored.
REF<x>:HORizontal:DELay:TIMe? on page 201 Returns the horizontal position of the specified
reference waveform in percent of the waveform
that is displayed to the right of the center vertical
graticule.
REF<x>:HORizontal:SCAle? on page 202 Returns the horizontal scale for the reference
waveform.
REF<x>:HORizontal:SCAle? on page 202 Returns the vertical position for channel <x>,
where x is the reference channel number.
REF<x>:VERTical:POSition? on page 203 Returns the vertical position of the specified
reference waveform.
REF<x>:VERTical:SCAle? on page 203 Returns the reference waveform vertical scale in
vertical units/div.
SELect:CH<x> on page 212 Turns the display of the channel <x> waveform
on or off.
SELect:CONTROl on page 213 Sets or returns the waveform that is selected as
the implied recipient of channel-related
commands
SELect:FFT on page 214 Turns on or off the FFT waveform or queries
whether the FFT waveform is on or off.
Command groups
TBS2000 Series Programmer 29
