YASKAWA A1000

1.5 Component Names
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 39
Receiving
1
 Three-Phase AC400 V CIMR-A4A0414A
Figure 1.6
Figure 1.6 Exploded view of IP00 Enclosure Type Components (CIMR-A4A0414A)
A – Fan guard I – Digital operator
B – Cooling fan J – USB port (type-B)
C – Fan unit case K – Front cover
D – Circulation fan L – Terminal board
E – Front cover screw M – Optional 24 V DC power
supply connector cover
F – Drive cover 1
G – Drive cover 2 N – Heatsink
H – Terminal cover O – Mounting hole
O
N
M
J
I
G
H
C
D
B
A
F
E
L
K
