B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 457
b4: Timer Function
b3-19
(1F2H)
Number of Speed Search Restarts
Sets the number of times the drive can attempt to restart when performing Speed Search.
Default: 3
Min: 0
Max: 10
165
b3-24
(1C0H)
Speed Search Method Selection
0: Current Detection
1: Speed Estimation
Default: 0
Min: 0
Max: 1
165
b3-25
(1C8H)
Speed Search Wait Time
Sets the time the must wait between each Speed Search restart attempt.
Default: 0.5 s
Min: 0.0 s
Max: 30.0 s
166
b3-26
(1C7H)
Direction Determining Level
Sets the level that determines the direction of motor rotation.
Note: This parameter is available in models CIMR-A4A0930 and 4A1200.
Default:
<9>
Min: 40
Max: 60000
166
b3-27
(1C9H)
Start Speed Search Select
Selects a condition to activate Speed Search Selection at Start (b3-01) or External Speed Search
Command 1 or 2 from the multi-function input.
0: Triggered when a Run command is issued (normal).
1: Triggered when an external baseblock is released.
Default: 0
Min: 0
Max: 1
166
b3-29
(77CH)
Speed Search Induced Voltage
Level
There is normally no need to change this parameter from the default value.
Performs Speed Search when the motor induced voltage exceeds the set level. If changes are
necessary, try lowering this value in small increments. If set too low, then the drive will not
perform Speed Search.
Note: This parameter is not available with models CIMR-A4A0930 and 4A1200.
Default: 10%
Min: 0%
Max: 10%
166
b3-33
(B3FH)
Speed Search Selection when
Driving Instruction is Input in Uv
Activates or deactivates the speed search at start in accordance with whether or not a Run
command was issued during an undervoltage (Uv) if operation during a momentary power loss
(L2-01 = 1 or 2), the speed search at start (b3-01 = 1), and coasting to a stop (b1-03 = 1) are
enabled.
0: Speed Search disabled
1: Speed Search enabled
Note: This parameter is not available with models CIMR-A4A0930 and 4A1200.
Default: 0
Min: 0
Max: 1
166
<9> Default setting value is dependent on the drive model (o2-04) and the Drive Duty (C6-01).
<10> Default setting is determined by the control mode (A1-02).
<16> Default setting is determined by the control mode (A1-02) and the drive model (o2-04).
No.(Addr.) Name Description Setting Page
b4-01
(1A3H)
Timer Function On-Delay Time
Used to set the on-delay and off-delay times for a digital timer output (H2-=12). The output
is triggered by a digital input programmed to H1-=18)
Default: 0.0 s
Min: 0.0 s
Max: 3000.0 s
167
b4-02
(1A4H)
Timer Function Off-Delay Time
Default: 0.0 s
Min: 0.0 s
Max: 3000.0 s
167
b4-03
(B30H)
H2-01 ON Delay Time
Sets the length of the delay time for contact outputs to open or close for the related functions set
in H2-.
Note: This parameter is not available with models CIMR-A4A0930 and 4A1200.
Default: 0 ms
Min: 0 ms
Max: 65535 ms
167
b4-04
(B31H)
H2-01 OFF Delay Time
b4-05
(B32H)
H2-02 ON Delay Time
b4-06
(B33H)
H2-02 OFF Delay Time
b4-07
(B34H)
H2-03 ON Delay Time
b4-08
(B35H)
H2-03 OFF Delay Time
No.(Addr.) Name Description Setting Page
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
All Modes
All Modes
All Modes
To Next Page
