YASKAWA A1000

C.9 MEMOBUS/Modbus Data Table
566 YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual
00D2H
CPF Contents 3
bit 0 ASIC Start-up Error (CPF32)
bit 1 Watch-dog Error (CPF33)
bit 2 ASIC Power/Clock Error (CPF34)
bit 3 External A/D Converter Error (CPF35)
bit 4 to 7 Reserved
bit 8 Control Circuit Error (CPF40)
bit 9 Control Circuit Error (CPF41)
bit A Control Circuit Error (CPF42)
bit B Control Circuit Error (CPF43)
bit C Control Circuit Error (CPF44)
bit D Control Circuit Error (CPF45)
bit E, F Reserved
00D3H to 00D7H Reserved
00D8H
oFA0 Contents (CN5-A)
bit 0 Option Compatibility Error (oFA00)
bit 1 Option not properly connected (oFA01)
bit 2 to 4 Reserved
bit 5 A/D Conversion Error (oFA05)
bit 6 Option Response Error (oFA06)
bit 7 to F Reserved
00D9H
oFA1 Contents (CN5-A)
bit 0 Option RAM Fault (oFA10)
bit 1 Option Operation Mode Fault (SLMOD) (oFA11)
bit 2 Drive Receive CRC Error (oFA12)
bit 3 Drive Receive Frame Error (oFA13)
bit 4 Drive Receive Abort Error (oFA14)
bit 5 Option Receive CRC Error (oFA15)
bit 6 Option Receive Frame Error (oFA16)
bit 7 Option Receive Abort Error (oFA17)
bit 8 to F Reserved
00DAH to 00DBH Reserved
00DBH
oFA3 Contents (CN5-A)
bit 0 Comm. ID Error (oFA30)
bit 1 Model Code Error (oFA31)
bit 2 Sumcheck Error (oFA32)
bit 3 Comm. option timeout waiting for response (oFA33)
bit 4 MEMOBUS Timeout (oFA34)
bit 5 Drive timeout waiting for response (oFA35)
bit 6 CI Check Error (oFA36)
bit 7 Drive timeout waiting for response (oFA37)
bit 8 Control Command Selection Error (oFA38)
bit 9 Drive timeout waiting for response (oFA39)
bit A Control Response Selection 1 Error (oFA40)
bit B Drive timeout waiting for response (oFA41)
bit C Control Response Selection 2 Error (oFA42)
bit D Drive timeout waiting for response (oFA43)
bit E, F Reserved
00DCH
oFb0 Contents (CN5-B)
bit 0 Option compatibility error (oFb00)
bit 1 Option not properly connected (oFb01)
bit 2 Same type of option card already connected (oFb02)
bit 3, 4 Reserved
bit 5 A/D Conversion Fault (oFb05)
bit 6 Option Response Error (oFb06)
bit 7 to F Reserved
00DDH
oFb1 Contents (CN5-B)
bit 0 Option RAM Fault (oFb10)
bit 1 Option Operation Mode Fault (SLMOD) (oFb11)
bit 2 Drive Receive CRC Error (oFb12)
bit 3 Drive Receive Frame Error (oFb13)
bit 4 Drive Receive Abort Error (oFb14)
bit 5 Option Receive CRC Error (oFb15)
bit 6 Option Receive Frame Error (oFb16)
bit 7 Option Receive Abort Error (oFb17)
bit 8 to F Reserved
00DEH to 00DFH Reserved
Register No. Contents
