C.9 MEMOBUS/Modbus Data Table
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 567
MEMOBUS/Modbus Communications
C
00E0H
oFb3 Contents (CN5-B)
bit 0 Comm. ID Error (oFb30)
bit 1 Model Code Error (oFb31)
bit 2 Sumcheck Error (oFb32)
bit 3 Comm. option timeout waiting for response (oFb33)
bit 4 MEMOBUS Timeout (oFb34)
bit 5 Drive timeout waiting for response (oFb35)
bit 6 CI Check Error (oFb36)
bit 7 Drive timeout waiting for response (oFb37)
bit 8 Control Command Selection Error (oFb38)
bit 9 Drive timeout waiting for response (oFb39)
bit A Control Response Selection 1 Error (oFb40)
bit B Drive timeout waiting for response (oFb41)
bit C Control Response Selection 2 Error (oFb42)
bit D Drive timeout waiting for response (oFb43)
bit E, F Reserved
00E1H
oFC0 Contents (CN5-C)
bit 0 Option compatibility error (oFC00)
bit 1 Option not properly connected (oFC01)
bit 2 Same type of option card already connected (oFC02)
bit 3, 4 Reserved
bit 5 A/D Conversion Fault (oFC05)
bit 6 Option Response Error (oFC06)
bit 7 to F Reserved
00E2H
oFC1 Contents (CN5-C)
bit 0 Option RAM Fault (oFC10)
bit 1 Option Operation Mode Fault (SLMOD) (oFC11)
bit 2 Drive Receive CRC Error (oFC12)
bit 3 Drive Receive Frame Error (oFC13)
bit 4 Drive Receive Abort Error (oFC14)
bit 5 Option Receive CRC Error (oFC15)
bit 6 Option Receive Frame Error (oFC16)
bit 7 Option Receive Abort Error (oFC17)
bit 8 to F Reserved
00E3H Reserved
00E4H
oFC5 Contents (CN5-C)
bit 0 Encoder Option AD Conversion Error (oFC50)
bit 1 Encoder Option Analog Circuit Error (oFC51)
bit 2 Encoder Communication Timeout (oFC52)
bit 3 Encoder Communication Data Error (oFC53)
bit 4 Encoder Error (oFC54)
bit 5 Resolver Error (oFC55)
bit 6 to F Reserved
00E5H Reserved
00E6H to 00FAH Reserved
00FBH Output Current
00FFH Reserved
<1> Units are determined by parameter o1-03.
<2> Display is in the following units.
 CIMR-A2A0004 to 2A0040, CIMR-A4A0002 to 4A0023: 0.01 A units
 CIMR-A2A0056 to 2A0312, CIMR-A4A0031 to 4A0675: 0.1 A units
 CIMR-A4A0930 to 4A1200: 1 A units
<3> The contents of a communication error are saved until the fault is reset.
<4> Depending on the motor used, the correct motor pole number must be set to parameter E2-04, E4-04, or E5-04.
Register No. Contents
