YASKAWA A1000 Technical Manual

D.2 European Standards
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 585
Standards Compliance
D
Figure D.7
Figure D.7 EMC Filter Dimensions (Manufacturer: Block)
 DC Reactors for IEC/EN 61000-3-2 Compliance
Table D.4 DC Reactors for Harmonics Reduction
Note: DC reactors are not required for other models to comply with EMC.
Drive Model
CIMR-A
DC Reactor
Model Rating
200V Three-Phase Units
2A0004
UZDA-B
5.4 A
8 mH
2A0006
400 V Three-Phase Units
4A0002
UZDA-B
3.2 A
28 mH
4A0004
Figure 1
Figure 3
Figure 5
Figure 4
Figure 2
H
W
D
Y
Y
Y
X
X
D
W
H
X X
Y
D
W
H
Y
X
D
W
H
X
H
Y
W
W
D
YEG

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
