D.3 UL Standards
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 595
Standards Compliance
D
Table D.9 Factory Recommended A1000 AC Drive Branch Circuit Protection (Heavy Duty)
Drive Model
<1> Maximum MCCB Rating is 15 A, or 200% of drive input current rating, whichever is larger. MCCB voltage rating must be 600 VAC or greater.
<2> Maximum Time Delay fuse is 175% of drive input current rating. This covers any Class CC, J or T class fuse.
<3> Maximum Non-time Delay fuse is 300% of drive input current rating. This covers any CC, J or T class fuse.
<4> When using semiconductor fuses, Bussmann FWH and FWP are required for UL compliance. Select FWH for 200 V Class and 400 V Class
models and FWP fuses for 600 V models.
<5> This covers Class L fuse.
A1000 in Heavy Duty Mode (C6-01 = 0)
AC Drive Input Amps MCCB Rating Amps <1>
Time Delay Fuse Rating
Amps <2>
Non-time Delay Fuse
Rating Amps <3>
Bussmann
Semiconductor Fuse
Rating (Fuse Ampere)
<4>
Three-Phase 200 V Class
2A0004 2.9 15 5 8 FWH-70B (70)
2A0006 5.8 15 10 15 FWH-70B (70)
2A0010 7.5 15 12 20 FWH-70B (70)
2A0012 11 20 17.5 30 FWH-70B (70)
2A0021 18.9 35 30 50 FWH-90B (90)
2A0030 28 50 40 75 FWH-100B (100)
2A0040 37 60 60 100 FWH-200B (200)
2A0056 52 100 90 150 FWH-200B (200)
2A0069 68 125 110 200 FWH-200B (200)
2A0081 80 150 125 225 FWH-300A (300)
2A0110 82 150 125 225 FWH-300A (300)
2A0138 111 200 175 250 FWH-350A (350)
2A0169 136 250 225 350 FWH-400A (400)
2A0211 164 300 250 450 FWH-400A (400)
2A0250 200 400 350 600 FWH-600A (600)
2A0312 271 500 450 800 FWH-700A (700)
2A0360 324 600 500 900
<5> FWH-800A (800)
2A0415 394 700 600 1100
<5> FWH-1000A (1000)
Three-Phase 400 V Class
4A0002 1.8 15 3 5 FWH-40B (40)
4A0004 3.2 15 5 9 FWH-50B (50)
4A0005 4.4 15 7 12 FWH-70B (70)
4A0007 6 15 10 17.5 FWH-70B (70)
4A0009 8.2 15 12 20 FWH-90B (90)
4A0011 10.4 20 17.5 30 FWH-90B (90)
4A0018 15 30 25 40 FWH-80B (80)
4A0023 20 40 35 60 FWH-100B (100)
4A0031 29 50 50 80 FWH-125B (125)
4A0038 39 75 60 110 FWH-200B (200)
4A0044 47 75 75 125 FWH-250A (250)
4A0058 43 75 75 125 FWH-250A (250)
4A0072 58 100 100 150 FWH-250A (250)
4A0088 71 125 110 200 FWH-250A (250)
4A0103 86 150 150 250 FWH-250A (250)
4A0139 105 175 175 300 FWH-350A (350)
4A0165 142 225 225 400 FWH-400A (400)
4A0208 170 250 250 500 FWH-500A (500)
4A0250 207 350 350 600 FWH-600A (600)
4A0296 248 400 400 700 FWH-700A (700)
4A0362 300 500 500 800 FWH-800A (800)
4A0414 346 600 600 1000
<5> FWH-800A (800)
4A0515 410 700 700 1200
<5> FWH-1000A (1000)
4A0675 584 1000 1000
<5> 1600 <5> FWH-1200A (1200)
4A0930 830
–
FWH-1200A (1200)
4A1200 1031 FWH-1600A (1600)
