E.3 User Setting Table
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 609
Quick Reference Sheet
E
F7-03 IP Address 3
F7-04 IP Address 4
F7-05 Subnet Mask 1
F7-06 Subnet Mask 2
F7-07 Subnet Mask 3
F7-08 Subnet Mask 4
F7-09 Gateway Address 1
F7-10 Gateway Address 2
F7-11 Gateway Address 3
F7-12 Gateway Address 4
F7-13 Address Mode at Startup
F7-14 Duplex Mode Selection
F7-15 Communication Speed Selection
F7-16 Communication Loss Time Out
F7-17 EtherNet/IP Speed Scaling Factor
F7-18 EtherNet/IP Current Scaling Factor
F7-19 EtherNet/IP Torque Scaling Factor
F7-20 EtherNet/IP Power Scaling Factor
F7-21 EtherNet/IP Voltage Scaling Factor
F7-22 EtherNet/IP Time Scaling
F7-23 to
F7-32
Dynamic Output Assembly Parameters
F7-33 to
F7-42
Dynamic Input Assembly Parameters
F7-60
PZD1 Write
F7-61
PZD2 Write
F7-62
PZD3 Write
F7-63
PZD4 Write
F7-64
PZD5 Write
F7-65
PZD6 Write
F7-66
PZD7 Write
F7-67
PZD8 Write
F7-68
PZD9 Write
F7-69
PZD10 Write
F7-70
PZD1 Read
F7-71
PZD2 Read
F7-72
PZD3 Read
F7-73
PZD4 Read
F7-74
PZD5 Read
F7-75
PZD6 Read
F7-76
PZD7 Read
F7-77
PZD8 Read
F7-78
PZD9 Read
F7-79
PZD10 Read
H1-01
Multi-Function Digital Input Terminal S1 Function
Selection
H1-02
Multi-Function Digital Input Terminal S2 Function
Selection
H1-03
Multi-Function Digital Input Terminal S3 Function
Selection
H1-04
Multi-Function Digital Input Terminal S4 Function
Selection
H1-05
Multi-Function Digital Input Terminal S5 Function
Selection
H1-06
Multi-Function Digital Input Terminal S6 Function
Selection
H1-07
Multi-Function Digital Input Terminal S7 Function
Selection
H1-08
Multi-Function Digital Input Terminal S8 Function
Selection
H2-01 Terminal M1-M2 Function Selection (relay)
H2-02 Terminal M3-M4 Function Selection (Relay)
H2-03 Terminal M5-M6 Function Selection (Relay)
H2-06 Watt Hour Output Unit Selection
H2-07 <1> Memobus Regs1 Address Select
H2-08 <1> Memobus Regs1 Bit Select
No. Name
User
Setting
H2-09 <1> Memobus Regs2 Address Select
H2-10 <1> Memobus Regs2 Bit Select
H3-01 Terminal A1 Signal Level Selection
H3-02 Terminal A1 Function Selection
H3-03 Terminal A1 Gain Setting
H3-04 Terminal A1 Bias Setting
H3-05 Terminal A3 Signal Level Selection
H3-06 Terminal A3 Function Selection
H3-07 Terminal A3 Gain Setting
H3-08 Terminal A3 Bias Setting
H3-09 Terminal A2 Signal Level Selection
H3-10 Terminal A2 Function Selection
H3-11 Terminal A2 Gain Setting
H3-12 Terminal A2 Bias Setting
H3-13 Analog Input Filter Time Constant
H3-14 Analog Input Terminal Enable Selection
H3-16 Terminal A1 Offset
H3-17 Terminal A2 Offset
H3-18 Terminal A3 Offset
H4-01
Multi-Function Analog Output Terminal FM Monitor
Selection
H4-02 Multi-Function Analog Output Terminal FM Gain
H4-03 Multi-Function Analog Output Terminal FM Bias
H4-04
Multi-Function Analog Output Terminal AM Monitor
Selection
H4-05 Multi-Function Analog Output Terminal AM Gain
H4-06 Multi-Function Analog Output Terminal AM Bias
H4-07
Multi-Function Analog Output Terminal FM Signal Level
Selection
H4-08
Multi-Function Analog Output Terminal AM Signal Level
Selection
H5-01 Drive Node Address
H5-02 Communication Speed Selection
H5-03 Communication Parity Selection
H5-04 Stopping Method After Communication Error (CE)
H5-05 Communication Fault Detection Selection
H5-06 Drive Transmit Wait Time
H5-07 RTS Control Selection
H5-09 CE Detection Time
H5-10 Unit Selection for MEMOBUS/Modbus Register 0025H
H5-11 Communications ENTER Function Selection
H5-12 Run Command Method Selection
H5-17 Operation Selection when Unable to Write into EEPROM
H5-18 <1> Filter Time Constant for Motor Speed Monitoring
H6-01 Pulse Train Input Terminal RP Function Selection
H6-02 Pulse Train Input Scaling
H6-03 Pulse Train Input Gain
H6-04 Pulse Train Input Bias
H6-05 Pulse Train Input Filter Time
H6-06 Pulse Train Monitor Selection
H6-07 Pulse Train Monitor Scaling
H6-08 Pulse Train Input Minimum Frequency
L1-01 Motor Overload Protection Selection
L1-02 Motor Overload Protection Time
L1-03 Motor Overheat Alarm Operation Selection (PTC input)
L1-04 Motor Overheat Fault Operation Selection (PTC input)
L1-05 Motor Temperature Input Filter Time (PTC input)
L1-08 <1> OL1 Current Lvl
L1-09 <1> OL1 Current Lvl (for 2nd motor)
L1-13 Continuous Electrothermal Operation Selection
L1-15 Motor 1 Thermistor Selection (NTC)
L1-16 Motor 1 Overheat Temperature
L1-17 Motor 2 Thermistor Selection (NTC)
L1-18 Motor 2 Overheat Temperature
L1-19 Operation at Thermistor Disconnect (THo) (NTC)
L1-20 Operation at Motor Overheat (oH5)
No. Name
User
Setting
