YASKAWA A1000

3.8 Main Circuit Wiring
80 YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual
4A0088
R/L1, S/L2, T/L3 25 16 to 70
M8
9.0 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 25 25 to 70
–, +1 – 25 to 70
+3 – 16 to 70
16 16 to 25
4A0103
R/L1, S/L2, T/L3 35 25 to 70
M8
9.0 to 11
(79
.7 to 97.4)
U/T1, V/T2, W/T3 35 25 to 70
–, +1 – 25 to 70
+3 – 25 to 70
16 16 to 25
4A0139
R/L1, S/L2, T/L3 50 35 to 95
M10
18 to 23
(
159 to 204)
U/T1, V/T2, W/T3 50 35 to 95
–, +1 – 50 to 95
+3 – 25 to 95
25 25
4A0165
R/L1, S/L2, T/L3 70 50 to 95
M10
18 to 23
(
159 to 204)
U/T1, V/T2, W/T3 70 70 to 95
–,+1 – 35 to 95
+3 – 50 to 95
35 25 to 35
4A0208
R/L1, S/L2, T/L3 95 35 to 95
M10
18 to 23
(
159 to 204)
U/T1, V/T2, W/T3 95 35 to 95
–, +1 – 35 to 150
+3 – 25 to 70
50 50 to 150
4A0250
R/L1, S/L2, T/L3 120 95 to 300
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 120 95 to 300
–, +1 – 70 to 300
+3 – 35 to 300
70 70 to 240
4A0296
R/L1, S/L2, T/L3 185 95 to 300
M12
32 to 40
(
283 to 354)
U/T1, V/T2, W/T3 185 95 to 300
–, +1 – 70 to 300
+3 – 35 to 300 M10
18 to 23
(
159 to 204)
95 95 to 240 M12
32 to 40
(283 to 354)
4A0362
R/L1, S/L2, T/L3 240 95 to 300
M12
32 to 40
(
283 to 354)
U/T1, V/T2, W/T3 240 95 to 300
–, +1 – 95 to 300
+3 – 70 to 300 M10
18 to 23
(
159 to 204)
120 120 to 240 M12
32 to 40
(283 to 354)
4A0414
R/L1, S/L2, T/L3 95  2P 95 to 150
M12
32 to 40
(
283 to 354)
U/T1, V/T2, W/T3 95  2P 95 to 150
–, +1 – 70 to 150
+3 – 70 to 150
95 35 to 95
4A0515
R/L1, S/L2, T/L3 120  2P 95 to 150
M12
32 to 40
(
283 to 354)
U/T1, V/T2, W/T3 150  2P 95 to 150
–, +1 – 70 to 150
+3 – 70 to 150
150 50 to 150
Model
CIMR-A
Terminal
Recomm. Gauge
mm
2
Applicable
Gauge
mm
2
Screw
Size
Tightening
Torque
Nm (lb.in.)
