YASKAWA DX100 Instructions

8 System Setup
DX100 8.6 Interference Area
8-72
8.6.4 Clearing the Interference Area Data
1. Select {ROBOT} under the main menu.
2. Select {INTERFERENCE}.
– The INTERFERENCE AREA window is shown.
3. Select interference signal to be cleared.
– Select the desired interference signal number to be cleared using
the page key or by number input.
– When selecting the desired interference signal number by number
input, select {PAGE} to input the desired signal number.
长沙工控帮教育科技有限公司
工控帮助教小舒QQ:2823408167

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
