YASKAWA DX100 Instructions

8 System Setup
DX100 8.19 Display Setting Function
8-136
– The dialog box closes without changing the current screen layout.
8.19.4 Layout Storage
The settings of the font or button sizes are saved in the programming
pendant. The screen displays the font/button size specified last time with
the current programming pendant.
NOTE
Do not turn OFF the DX100 power supply when the screen
layout is being initialized (when the confirmation dialog box
is on the screen, or when an hourglass is indicated in the
middle of the screen).
长沙工控帮教育科技有限公司
工控帮助教小舒QQ:2823408167

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
