6-72
IM DLM6054-01EN
Reference Condition (Condition)
Select whether the mask test or eye pattern value of the source waveform must be in or out of the
determination range to produce a NO-GO result.
• IN:
The value must be inside of the determination range.
• OUT: The value must be outside of the determination range.
• X: The value is not used for GO/NO-GO determination.
Note
Because the sample point count is calculated using interpolated data, the value returned for it may not
correspond to the record length.
6.17 Performing GO/NO-GO Determination with Mask Tests and Eye Patterns
