18-1
IM DLM6054-01EN
Specifications
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18.1 Signal Input Section
Analog Signal Input
Item Specifications
Number of input channels 4(CH1 to CH4)
Input coupling settings
Input connector BNC connector
Input impedance
Selectable voltage sensitivity
range
2 mV/div to 5 V/div(in 1-2-5 steps)
2 mV/div to 500 V/div(in 1-2-5 steps)
Maximum input voltage 150 Vrms CAT
I (At 100 kHz and higher) I (At 100 kHz and higher)
5 Vrms or less and 10 Vpeak or less
Selectable maximum DC offset
range
(When the probe attenuation is
set to 1:1)
2 mV/div to 50 mV/div:: ±1 V
100 mV/div to 500 mV/div:: ±10 V
1V/div to 5V/div:: ±100 V
2 mV/div to 50 mV/div:: ±1 V
100 mV/div to 500 mV/div:: ±5 V
Vertical-axis (voltage-axis)
accuracy
DC accuracy
1
±(1.5% of 8 divisions + offset voltage accuracy)
Offset voltage accuracy
1
2 mV/div to 50 mV/div: ±(1% of set value + 0.2 mV)
100 mV/div to 500 mV/div: ±(1% of set value + 2 mV)
1 V/div to 5 V/div: ±(1% of set value + 20 mV)
Voltage standing wave ratio
(VSWR)
Less than 1.5 within the frequency band (typical value)
4
1, 2
(When sine wave with amplitude
±3 div
P-P
equivalent is input)
DL6054/DLM6054 DL6104/DLM6104 DL6154
50V/div to 100mV/div:: DC to 500MHz DC to 500MHz DC to 500MHz
50mV/div to 20mV/div:: DC to 400MHz DC to 400MHz DC to 400MHz
500mV/div to 10mV/div:: DC to 500MHz DC to 1.0GHz DC to 1.5GHz
5mV/div: DC to 400MHz DC to 750MHz DC to 1.0GHz
2mV/div:: DC to 400MHz DC to 600MHz DC to 750MHz
–3 dB point for AC coupling 10 Hz or less (1 Hz or less when using the supplied 10:1 probe)
Skew between channels
(when channels are set to the
same conditions)
1 ns or less
Residual noise level
3
0.4 mVrms or 0.05 divisions rms, whichever is greater (typical value
4
)
Isolation between channels
(when set to the same voltage
sensitivity)
DL6054/DLM6054 DL6104/DLM6104 DL6154
Maximum bandwidth: –34 dB
(typical value
4
)
–30 dB30 dB
(typical value
4
)
–30 dB30 dB
(typical value
4
)
A/D converter resolution 8 bit(25 LSB/div)
12 bits maximum (during high-resolution mode)
Probe attenuation settings Voltage probe: Auto, 1:1, 2:1, 5:1, 10:1, 20:1, 50:1, 100:1, 200:1, 500:1, 1000:1
Current probe: Auto, 1A:1V, 10A:1V, 100A:1V
Bandwidth limit For each channel, can be set to FULL, 200 MHz, 20 MHz, 8 MHz, 4 MHz, 2 MHz, 1 MHz,
500 kHz, 250 kHz, 125k Hz, 62.5 kHz, 32 kHz, 16 kHz, or 8 kHz
Accomplished through the combination of an analog (200 and 20 MHz) and digital (IIR + FIR)
filter.
Maximum sample rate Real-time sampling mode. Values inside parentheses are for high resolution mode.
DL6054/DLM6054 DL6104/DLM6104 DL6154
When interleave mode is on:
5 GS/s(2.5GS/s) 5 GS/s(2.5GS/s) 10 GS/s(5GS/s)
When interleave mode is off:
2.5 GS/s(1.25GS/s) 2.5 GS/s(1.25GS/s) 5 GS/s(2.5GS/s)
Repetitive sampling mode: 2.5 TS/s 2.5 TS/s 2.5 TS/s
Interpolation sampling mode: 2.5 TS/s 2.5 TS/s 2.5 TS/s
Chapter 18 Specifications
