18-17
IM DLM6054-01EN
Specifications
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18.10 Computer Interface
PC Card Interface
Item Specifications
Number of ports 1
Compatible cards
1
GP-IB card (option support): National Instruments NI PCMCIA-GPIB cards supported
Storage cards: Flash ATA memory cards (PC card TYPE II)
CF card + adapter card
HDD-type PC cards
1 For details on compatible devices, contact your nearest YOKOGAWA dealer.
USB-PC Connection
Item Specifications
Connector type USB type B connector (receptacle)
Electrical and mechanical
specifications
USB Rev. 2.0 compliant
Supported transfer standards FS (Full Speed) mode (12 Mbps) and HS (High Speed) mode (480 Mbps)
Number of ports 1
Supported protocols Acts as a composite device simultaneously supporting the following two protocols.
USBTMC-USB488(USB Test and Measurement Class Ver.1.0)
1
USB bus can be used with GPIB commands.
Mass Strage Class Ver.1.1
Access from a PC to the internal memory, PC card,
2,3
USB mass-storage device is possible
(reading and writing). However, formatting is not possible.
Compatible PC systems A PC running Windows XP/2000 English/Japanese version, equipped with a USB port.
1 A separate driver is required.
2 No drivers are required.
3 For details on compatible devices, contact your nearest YOKOGAWA dealer.
LXI Interface (/C9 or /C12 Option)
Item Specifications
Connector type RJ-45 connector
Ports 1
Electrical and mechanical
specifications
IEEE 802.3 compliant
Transmission system Ethernet(1000BASE-T/100BASE-TX/10BASE-T)
Communication protocol TCP/IP
Supported services DHCP, DNS, Microsoft network file sharing server and client, SMTP client, SNTP client,
FTP server, Web server, network printer, and firewall
LED indicators Two indicators: Link, which illuminates in yellow when a link is established, and Activity,
which illuminates in green when packets are being transmitted or received
Compliant standard LXI Standard, Revision 1.2
Functional class Class C
