18.2 Triggering Section
Item Specifications
Trigger modes Auto, Auto Level, Normal, Single, N Single
The DL6000/DLM6000 measures in Single mode when you start acquisition by pressing the
SINGLE key.
Trigger sources CH1 to CH4:: Signals received through input terminals
LINE:: The connected commercial power supply signal (only Edge
trigger can be used)
EXT:: The signal received through the TRIG IN terminal
PodA to PodD
3
(Logic):: Signals received through the logic signal input port terminals
Trigger coupling CH1 to CH4:: DC/AC
EXT:: DC
HF rejection Trigger source bandwidth limit can be specified separately for CH1 to CH4
OFF:: No bandwidth limit
15kHz:: DC to approximately 15 kHz
20MHz:: DC to approximately 20 MHz
Trigger hysteresis Trigger level hysteresis can be selected for CH1 to CH4 separately.
Trigger level hysteresis cannot be specified on channels set to TV trigger.
High:: Apply a hysteresis of approx. 1.0 division around the trigger
level
Low:: Apply a hysteresis of approx. 0.3 division around the trigger
level
Selectable trigger level range CH1 to CH4: ±4 divisions from the screen center
EXT: ±2 V(with a 1:1 probe), ±20 V(with a 10:1 probe), ±20 V(with a 10:1 probe)±20 V(with a 10:1 probe)
PodA to PodD
3
(Logic): Determined by the threshold levels
Trigger level resolution CH1 to CH4: 0.01 divisions (0.1 divisions for TV triggers)
EXT: 5 mV(with a 1:1 probe), 50 mV(with a 10:1 probe), 50 mV(with a 10:1 probe)50 mV(with a 10:1 probe)
Trigger level accuracy CH1 to CH4
1
: ±(0.2 divisions + 10% of the trigger level)
EXT
2
: ±(50 mV + 10% of the trigger level)
Window comparator setting Window comparator can be turned on or off for CH1 to CH41 separately
OFF: Normal comparator
Edge polarities: Rise and Fall. Qualifications: H, L, and X.
ON: Window comparator
Edge polarities: Enter and Exit. Qualifications: IN, OUT, and X.
Selectable window trigger level
range
Can be set separately for CH1 to CH4
Center: ±4 divisions from the screen center
Width: ±4 divisions around the center
Window trigger level accuracy The following trigger level accuracy applies to the upper and lower limits of the window that are
specified using the Center and Width settings. The upper and lower limits are set separately for
CH1 to CH4
±(0.2 divisions + 10% of the trigger level)
However, the accuracy does not apply to an upper or lower limit that falls outside ±4 divisions
from the screen center.
External trigger probe
attenuation setting
1:1, 10:1:1, 10:11, 10:1, 10:110:1:11
Trigger sensitivity
1
DL6054/DLM6054 DL6104/DLM6104 DL6154
CH1 to CH4: 1div
P-P
DC to 500MHz
4
DC to 1GHz
4
DC to 1GHz
4
EXT: 100mV
P-P
DC to 100MHz DC to 100MHz DC to 100MHz
Edge OR: 1div
P-P
DC to 50MHz DC to 50MHz DC to 50MHz
Trigger position Can be set as a percentage of the display record length in 0.1% steps
Selectable trigger delay range -(Time length of the post-trigger section) to 10 s Resolution:(1/sample rate)×100 Resolution:(1/sample rate)
×100×100100
Selectable hold-off time range 20 ns to 10 s , Resolution: 5ns5ns
