14.7 Using a PC to Monitor the DL6000/DLM6000
and Change Its Settings (Web Server)
Procedure
UTILITY Network Menu
Press UTILITY, the Network soft key, and then the Server Setup soft key to display the following
menu.
Set the file server feature to Web.
Turns authentication on and off
Set the user name.
Set the password.
Applies the settings
Connecting a PC to the DL6000/DLM6000
Open a Web browser on a PC that is connected to the network.
In the browser’s address bar, enter “http://,” followed by the IP address of the DL6000/DLM6000.
If authentication has been enabled on the DL6000/DLM6000, a dialog box for entering the user name
and password appears. Enter the user name and password that you specified in the above menu.
If the PC connects to the DL6000/DLM6000 Web server successfully, the following top page will
appear.
Link to the LXI Consortium website
Connection status show/hide setting
Communication settings
Security settings
Monitoring
Links to the YOKOGAWA website
and product pages
Model
Manufacturer
Serial number
Product
LXI class
LXI version
Host name
MAC address
TCP/IP address
Firmware version
VISA resource string
