YOKOGAWA DL6000 Series User Manual

iii
IM DLM6054-01EN
Checking the Package Contents
After receiving the product and opening the package, check the items described below. If the wrong
items have been delivered, if items are missing, or if there is a problem with the appearance of the
items, contact your nearest YOKOGAWA dealer.
DL6000/DLM6000
Check that the product that you received is what you ordered by referring to the model name and suffix
code given on the name plate on the rear panel.
Name Plate
MODEL Suffix Code Description
DL6054 DL6054 Digital Oscilloscope, 4 ch, 5 GS/s, 500 MHz, max 6.25 Mpoints/
CH
DL6104 DL6104 Digital Oscilloscope, 4 ch, 5 GS/s, 1 GHz, max 6.25 Mpoints/CH
DL6154 DL6154 Digital Oscilloscope, 4 ch, 10 GS/s, 1.5 GHz, max 6.25 Mpoints/
CH
DLM6054 DLM6054 Mixed Signal Digital Oscilloscope, 4 ch + 16 or 32 bits, 5 GS/s,
500 MHz, max 6.25 Mpoints/CH
DLM6104 DLM6104 Mixed Signal Digital Oscilloscope, 4 ch + 16 or 32 bits, 5 GS/s,
1 GHz, max 6.25 Mpoints/CH
Power cord -D UL/CSA Standard power cord (Part No.: A1006WD)
[Maximum rated voltage: 125 V]
-F VDE Standard Power Cord (Part No.: A1009WD)
[Maximum rated voltage: 250 V]
-Q BS Standard Power Cord (Part No.: A1054WD)
[Maximum rated voltage: 250 V]
-R AS Standard Power Cord (Part No.: A1024WD)
[Maximum rated voltage: 250 V]
-H GB Standard Power Cord (Part No.: A1064WD)
[Maximum rated voltage: 250 V]
Logic input -L16
1
-L32
1
16-bit logic input
32-bit logic input
Language
(Menu and
Pannel)
-HE
-HJ
-HC
-HK
-HG
-HF
-HL
-HS
English
Japanese + English
Chinese + English
Korean + English
German + English
French + English
Italian + English
Spanish + English
Options /B5
/P2
2
/P4
2
/C9
3
/C12
3
/G2
4
/G4
4
/F3
5
/F4
5
Built-in printer
2 probe power terminals
4 probe power terminals
Internal storage + LXI-compatible Ethernet interface (LXI option)
LXI-compatible Ethernet interface (LXI option)
User-defined computation
Power supply analysis feature (includes user-defined computation)
UART + I
2
C + SPI Triggering and Analysis Features
UART + CAN + LIN Triggering and Analysis Features
1 Suffix codes -L16 and -L32 are not available for the DL6054, DL6104, or DL6154.
2 /P2 is an option for the DL6054, DL6104, and DL6154, while /P4 is for the DLM6054 and DLM6104.
3 Options /C9 and /C12 cannot both be installed on the same instrument.
4 Options /G2 and /G4 cannot both be installed on the same instrument. Option /G4 includes option /G2.
5 Options /F3 and /F4 cannot both be installed on the same instrument.
