17-10

IM DLM6054-01EN

17.6 Formatting Flash Memory

Procedure

UTILITY Storage Manager Menu

Press UTILITY, the Next soft key, and then the Storage Manager soft key to display the following

menu.

2. Select OK, and then press SET to begin formatting.

1. Formats the flash memory

(A confirmation dialog box appears.)

Explanation

You can format flash memory. Save the data that you want to keep to a PC or other device.
