14.9 Checking Whether or Not the DL6000/DLM6000

Has an Ethernet Interface

Procedure

UTILITY Overview Menu

Press UTILITY and then the Overview soft key to display the following menu.

Equipped with an Ethernet interface

Explanation

Checking for an Ethernet Interface

If the DL6000/DLM6000 has an Ethernet interface, the indication “LXI compliant Ethernet (/C12)” or

“Storage+LXI compliant Ethernet (/C9)” will appear in the system overview.
