4.2 Entering Values and Strings
Entering Values
Using Dedicated Knobs
You can use the following dedicated knobs to set values directly.
• POSITION knobs (VERTICAL and HORIZONTAL)
• SCALE knob (VERTICAL)
• TIME/DIV knob
• LEVEL
knob (TRIGGER)
• ZOOM knob
Using the Jog Shuttle
Select the appropriate item using the soft keys, and change the value using the jog shuttle and the
SET key.
This manual sometimes describes this operation simply as “using the jog shuttle.”
Note
Items that can be set using the jog shuttle are reset to their default values when you press the RESET key.
