16.2 Viewing Setup Information

Procedure

UTILITY Setup Information Menu

Press UTILITY and then the Next soft key to display the following menu.

Displays setup information

Setup Information Display Example

Set which page to show on the screen.

Explanation

You can view a list of setup information. The list contains multiple pages. You can select and view one

page at a time.
