Appendix 2 104 USB Keyboard Key Assignments
Panel Key USB Keyboard
CH1 Ctl-1
CH2 Ctl-2
CH3 Ctl-3
CH4 Ctl-4
LOGIC Ctl-l
MATH/REF Ctl-b
MODE Ctl-t
EDGE Ctl-w
ENHANCED Ctl-e
B TRIG Ctl-y
“ACTION/GONOGO
(SHIFT-MODE)” Ctl-Shift-t
RUN/STOP F12
SINGLE F11
ACQUIRE Ctl-a
DELAY F9
CURSOR Ctl-n
MEASURE Ctl-m
ANALYSIS Ctl-k
SEARCH Ctl-o
“XY
(SHIFT-DISPLAY)” Ctl-Shift-d
“FFT
(SHIFT-MATH/REF)” Ctl-Shift-b
“TELECOM TEST
(SHIFT-MEASURE)” Ctl-Shift-m
DISPLAY Ctl-d
ZOOM1 Ctl-z
ZOOM2 Ctl-x
SETUP Ctl-s
AUTO SETUP Ctl-i
HELP Ctl-/
HISTORY Ctl-h
CLEAR TRACE Ctl-q
SNAP SHOT Pause
PRINT Print
“PRINT MENU
(SHIFT-PRINT)” Shift-Print
FILE Ctl-f
UTILITY Ctl-u
ESC ESC
F1 F1
F2 F2
F3 F3
F4 F4
F5 F5
F6 F6
F7 F7
SET Ctl-Return
RESET Ctl-r
  
    (moving the SET key up) 
      (moving the SET key down) 
        (moving the SET key to the left) 
        (moving the SET key to the right) 
