YOKOGAWA DL6000 Series User Manual

App-3
IM DLM6054-01EN
Appendix
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Index
App
Panel Key USB Keyboard
Knob
V SCALE R (zoom in) End
V SCALE L (zoom out) Home
V SCALE PUSH(Fine) F10
V POS R(Up) Ctl-End
V POS L(Down) Ctl-Home
V POS PUSH(RESET) Ctl-v
TRIG LEV R(Up) 
TRIG LEV L(Down) 
TRIG LEV PUSH(Auto) Ctl-p
H SCALE R (zoom in) PageDown
H SCALE L (zoom out) PageUp
H POS R Ctl-PageUp
H POS L Ctl-PageDown
H POS PUSH(Reset) F8
MAG R (zoom out) Ctl-Del
MAG L (zoom in) Ctl-Ins
JOG R(Up) 
JOG L(Down) 
Appendix 2 104 USB Keyboard Key Assignments
