13-2
IM DLM6054-01EN
13.2 Connecting a USB Storage Device to a USB
Port
When connecting a USB storage device to a DL6000/DLM6000 USB port, connect the USB cable
directly as shown in the figure below. You can connect or disconnect a USB cable at any time
regardless of whether the DL6000/DLM6000 is on or off (hot-plugging is supported). Connect the type
A connector of the USB cable to the DL6000/DLM6000, and connect the type B connector to the USB
storage device. If you connect a USB storage device when the power switch is on, the device becomes
available for use after the DL6000/DLM6000 identifies it.
USB storage medium
USB cable
DL6000/
DLM6000
Note
• Connect USB storage devices directly, not through a USB hub.
• Only connect a compatible USB keyboard, mouse, printer, or storage device to a USB port for peripherals.
• Do not connect and disconnect multiple USB devices repetitively. Leave a 10-second interval between
removal and connection.
• Do not connect or remove USB cables from the time when the DL6000/DLM6000 is turned on until key
operation becomes available (approximately 20 to 30 seconds).
• You can use USB storage devices that are compatible with USB Mass Storage Class Ver. 1.1.
• The total number of storage devices that you can connect to the DL6000/DLM6000, including both PC
cards and USB storage devices, is four. If the connected medium is partitioned, the DL6000/DLM6000
treats each partition as a separate storage medium. As such, the DL6000/DLM6000 can handle up to four
partitions.
Confirming What Connected USB Storage Devices Can Be Used
Press FILE and then the Utility soft key to display a list of files.
Follow the procedure in section 13.10 to make the current folder the highest level in the folder
hierarchy.
The devices that can be used appear.
Usable media
To Next Page
