YOKOGAWA DL6000 Series User Manual

15-1
IM DLM6054-01EN
Rear Panel Input and Output
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Index
App
15.1 External Trigger Input (TRIG IN)
CAUTION
Only apply signals that meet the following specifications. Signals that do not meet the
specifications, such as those with excessive voltage, may damage the DL6000/DLM6000.
External Trigger Input Terminal
This terminal is used when an external signal is used as the trigger source (see section 6.3 for details).
TRIG IN
Item Specifications
Connector type BNC
Maximum input voltage ±40 V (DC + ACpeak) or 28 Vrms when the frequency is 10 kHz or less
Input frequency bandwidth DC to 100 MHz
Input impedance
Approx. 1 M
Ω
, approx. 18 pF
Trigger sensitivity 0.1 VP-P
Trigger level ± 2 V (resolution: 5 mV)
Chapter 15 Rear Panel Input and Output
