18-16
IM DLM6054-01EN
18.9 Auxiliary I/O Section
External Trigger Input (TRIG IN)
Item Specifications
Connector type BNC
Input bandwidth
1
DC to 100MHz
Input impedance
Maximum input voltage ±40 V (DC + ACpeak) or 28 Vrms, when the frequency is less than or equal to 10 KHzr
Input range ±2V
Trigger level ±2V, The resolution is 5 mV
1 Values measured under standard operating conditions (see section 18.11 for details) after a 30-minute warm-up.Values measured under standard operating conditions (see section 18.11 for details) after a 30-minute warm-up.
Trigger Output (TRIG OUT)
Item Specifications
Connector type BNC
Output level 5V TTL
Output logic Negative logic
Output delay 50ns Max
Output hold time Negative logic: Low level: 50 ns min. High level: 50 ns min.
Video Signal Output (VIDEO OUT)
Item Specifications
Connector type D-sub 15 pin (receptacle)
Output type Analog RGB output
Output resolution XGA-compliant output, 1024 × 768 dots, approx. 60-Hz Vsync (62.5-MHz dot clock
frequency)
GO/NO-GO Output (GO OUT, NO-GO OUT)
tem Specifications
Connector type RJ-12 modular jack
Output signal GO OUT, NO-GO OUT
Output level TTL compatible
Compliant cable Four-wire modular cable
Probe Interface Terminal
tem Specifications
Output terminals 4
Output voltage ±12 V (up to 1.2 A in combination with the rear-panel probe power terminal), ±5 V (up to 800
mA total)
Usable probes Active probes (701912, 701913, 701914), differential probes (701923, 701924),
urrent probes (701928, 701929)
Probe Power Terminal (/P4 Option)
tem Specifications
Output terminals 2(DL6000)
4(DLM6000)
Output voltage ±12 V (up to 1.2 A in combination with the probe interface terminal)
Usable probes and deskew
signal sources
FET probe (700939), current probe (701930, 701931, 701932, 701933), differential probes
(700924, 700925, 701920, 701921, 701922, 701926), deskew signal source (701935)
