YOKOGAWA DL6000 Series User Manual

18-7
IM DLM6054-01EN
Specifications
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Index
App
18.3 Time Axis
Item Specifications
Selectable time scale range 500ps/division to 50 s/division (in 1-2-5 steps) steps))
Timebase accuracy
1
±0.001%%
Time measurement accuracy
1
±(0.001% 10ps + 1 sample period)% 10ps + 1 sample period)10ps + 1 sample period) + 1 sample period))
1 Values measured under standard operating conditions (see section 18.11 for details) after a 30-minute warm-up.Values measured under standard operating conditions (see section 18.11 for details) after a 30-minute warm-up.
18.4 Display
Item Specifications
Display 8.4-inch (21.3-cm) color TFT LCD
Display screen size 170.5 mm (horizontal) × 127.9 mm (vertical)
Resolution of the entire screen
1
1024 × 768 (XGA)
Resolution of the waveform display 800 × 640
1 The LCD may include a few defective pixels (within 4 ppm over the total number of pixels including RGB).The LCD may include a few defective pixels (within 4 ppm over the total number of pixels including RGB).
The LCD may contain some pixels that are always lighted or that never light. Please be aware that these are not defects.
