18-6
IM DLM6054-01EN
Item Specifications
I2C
6
: Triggers on an I
2
C bus signal.
The source can be set to a signal from CH1 to CH4 or from logic bits PodA(0 to
7), PodD(0 to 7)
3
Mode:: Every Start, Adr Data, NON ACK, General Call,
Start byte/HS Mode
SPI
6
: Triggers on an SPI (Serial Peripheral Interface) bus signal
The source can be set to a signal from CH1 to CH4 or from logic bits PodA(0 to PodA(0 to
7), PodD(0 to 7)
3
Mode:: 3wire, 4wire
Serial:: Triggers on a general-purpose serial communication signal
The source can be selected from PodA (0 to 7) to PodD (0 to 7).
2
Data channel, chip select channel, clock channel, and latch channel can be
specified.
Bitrate: 1 k to 50 Mbps (without clock)
Bit length: 1 to 128bits
TV Triggers on the specified field number, line number, or polarity in video signals
of various broadcasting formats.
The source can be set to a channel from CH1 to CH4.
Mode:: NTSC: Triggers on an NTSC (525/60/2) signa
PAL:: Triggers on a PAL (625/50/2) signal
SDTV:: SDTV(480/60p) signal
HDTV:: Triggers on an SDTV (480/60p) signal
1080/60p, 1080/60i, 1080/50i, 1080/25p,
1080/24p, 1080/24sF, 720/60p, 1125/60/2
User def TV:: You can trigger on any TV signal by selecting
standard or high definition, setting the H sync
period, and setting the sync guard.
Sync guard can be set to a value from 60 to
90% of the H sync value in 1% steps.
Porality:: Pos, Neg
HF Rej:: NTSC/PAL:: 300 kHz
SDTV/HDTV:: OFF
User Def:: Select from OFF or 300 kHz
Line:: 5 to 1054(NTSC), 2 to 1251(PAL), 8 to 2251(SDTV),
2 to 2251(HDTV), 2 to 2251(User def TV)
Field:: 1, 2, X
Frame Skip:: 1, 2, 4, 8
AB trigger Able to trigger on the combination of triggers A and B
Trigger B can only be set to an Edge trigger.
(see Trigger Type (A trigger))
OFF:: Triggers only on the trigger A conditions (the trigger B conditions are not used).
A Delay B:: After the trigger A conditions are met and the specified amount of time elapses,
the DL6000/DLM6000 triggers when the trigger B conditions are met.
Delay value: 10ns to 10s
A to B(N):: After the trigger A conditions are met, the DL6000/DLM6000 triggers when the
trigger B conditions are met N times.
N value: 1 to 10
9
1 Values measured under standard operating conditions (see section 18.11 for details) after a 30-minute warm-up and
calibration.
2 Values measured under standard operating conditions (see section 18.11 for details) after a 30-minute warm-up.
3 16 bits model: PodA0 to 7, PodC0 to 7 bits model: PodA0 to 7, PodC0 to 7PodA0 to 7, PodC0 to 7
32 bits model: PodA0 to 7, PodB0 to 7, PodC0 to 7, PodD0 to 7 bits model: PodA0 to 7, PodB0 to 7, PodC0 to 7, PodD0 to 7PodA0 to 7, PodB0 to 7, PodC0 to 7, PodD0 to 7
4 When HF Rejection is set to OFF.
5 Typical values represent typical or average values. They are not strictly warranted.
6 CAN, LIN, I2C, SPI, and UART are options.
