18-2
IM DLM6054-01EN
Item Specifications
Maximum record length 6.25 M Points Stays the same whether interleave mode is on or off
Maximum acquisition rate 1.25M Points 60 waveform/s/channel
12.5k Pokints 9000 waveform/s/channel
2.5k Points 25000 waveform/s/channel
Dead time in N Single mode
5
400 ns or less (equivalent to 2.5 million waveforms per second)
1 Values measured under standard operating conditions (see section 18.11 for details) after a 30-minute warm-up and Values measured under standard operating conditions (see section 18.11 for details) after a 30-minute warm-up and
calibration.
2 Values for repeating phenomena. Values for repeating phenomena.
The single-shot frequency bandwidth is from DC to the sampling frequency/2.5 or is the frequency bandwidth of the
repeating phenomena, whichever is less.
3 Values when the input section is shorted, the acquisition mode is set to Normal, accumulation is set to off, and the probe Values when the input section is shorted, the acquisition mode is set to Normal, accumulation is set to off, and the probe
attenuation is set to 1:1.
4 ypical values represent typical or average values. They are not strictly warranted. ypical values represent typical or average values. They are not strictly warranted.
5 The number of inputs does not affect the acquisition rate. The number of inputs does not affect the acquisition rate.
Logic Signal Input (DLM6000))
Item Specifications
Usable probes 701980, 701981, 701988, 701989 (8-bit input))
Number of inputs 16 (on 16-bit models with 2 logic probe IFs using 2 logic probes)
Pod A(0 to 7), Pod C(0 to 7) to 7), Pod C(0 to 7)Pod C(0 to 7) to 7)
32(on 32-bit models with 4 logic probe IFs using 4 logic probes)
Pod A(0 to 7), Pod B(0 to 7), Pod C(0 to 7), Pod D(0 to 7) to 7), Pod B(0 to 7), Pod C(0 to 7), Pod D(0 to 7)Pod B(0 to 7), Pod C(0 to 7), Pod D(0 to 7) to 7), Pod C(0 to 7), Pod D(0 to 7)Pod C(0 to 7), Pod D(0 to 7) to 7), Pod D(0 to 7)Pod D(0 to 7) to 7)
Nondestructive maximum input
voltage
701980, 701981, 701989:, 701981, 701989:701981, 701989:, 701989:: ±40V(DC + ACpeak) or 28Vrms
701988: ±42V(DC + ACpeak) or 29Vrms
For information about derating based on frequency, see the respective logic probe user's
manual.
When using the
701980
When using the
701981
When using the
701988
When using the 701989
Input range ±40V ±10V ±40V Threshold level ±6V
Minimum input voltage 500mV
P-P
500mV
P-P
500mV
P-P
300mV
P-P
Maximum toggle frequency
1
100MHz 250MHz 100MHz 250MHz
Input impedance (typical value
3
)
Threshold level setting Same value for all 8
bits
Same value for all 8
bits
Same value for all 8
bits
Same value for all 8 bits
Variable threshold level range ±40V ±10V ±40V ±6V
Threshold level resolution 0.1V 0.1V 0.05V 0.05V
Threshold level accuracy
1
±(0.1 V + 3% of
setting)
±(0.1 V + 3% of
setting)
±(0.1 V + 3% of
setting)
±(0.1 V + 3% of setting)
Hysteresis voltage (typical value
3
) 80mV 50mV 100mV HFrejection
OFF: 100mV
ON: 250mV
Minimum pulse width 5ns 2ns 5ns 2ns
Logic channel threshold level
preset
You can choose from the following preset threshold level settings.
COMS(5V)=2.50V, CMOS(3.3V)=1.66V, CMOS(2.5V)=1.25V, CMOS(1.8V)=0.90V,
ECL=-1.30V
Maximum sample rate Real-time sampling mode. Values inside parentheses are for high resolution mode
2
When interleave mode is on: 5GS/s(2.5GS/s)
When interleave mode is off: 2.5GS/s(1.25GS/s)
Repetitive sampling mode:
interpolation
Interpolation sampling mode:
interpolation
Maximum record length
4
6.25M Points (stays the same whether interleave mode is on or off)
Maximum acquisition rate
4
1.25M Points 60 waveforms per second per channel
12.5K Points 9,000 waveforms per second per channel
2.5K Points 25,000 waveforms per second per channel
Dead time in N Single mode
4
400 ns or less (equivalent to 2.5 million waveforms per second)
1 Under standard operating conditions (see section 18.11 for details) after a 30-minute warm-up.
2 Resolution only improves for analog waveforms.
3 Typical values represent typical or average values. They are not strictly warranted.
4 The number of inputs does not affect the acquisition rate.
18.1 Signal Input Section
To Next Page
