Computed and Reference Waveforms

Index

App

Explanation

You can display reference waveforms when the computation mode is set to REF. If you set the

measurement source to a channel from M1 to M4 when a reference waveform is displayed, cursor

measurements and automated measurements of waveform parameters are performed relative to the

reference waveform.

You can specify equations that use the reference waveform while it is displayed.

(For example, when M1 is the reference waveform, you can specify the equation M2 = CH1 + M1.)

The following waveforms can be used as reference waveforms:

• Input waveforms (CH1 to CH4) and computed waveforms (M1

to M4).

• Waveforms saved in the past. (You can load a waveform using the FILE menu.)

History Waveform Display (History)

When you load a reference waveform, history waveforms are also loaded in addition to the currently

displayed waveform. This means that you can use the following history features on reference

waveforms. For details about history features, see chapter 11.

• Display mode settings (ONE,

All Half Tone, and Accumulate)

• Averaging (Average)

• History waveform replay (Replay)

• List display (List)

• Gradation mode (Grade; only when the display mode is

Accumulate)

Vertical Position (Position)

You can move the reference waveform vertical position within ±4 divisions.

9.8 Loading Reference Waveforms

YOKOGAWA DL6000 Series User Manual
