12-8
IM DLM6054-01EN
Connection Procedure
Connect a USB printer directly to the DL6000/DLM6000 using a USB cable as shown in the figure
below. You can connect or remove the USB cable regardless of whether or not the DL6000/DLM6000
power switch is turned on (hot-plugging is supported). Connect the type A connector of the USB
cable to the DL6000/DLM6000, and connect the type B connector to the printer. If you connect a
printer when the power switch is on, the printer becomes available for use after the DL6000/DLM6000
identifies the printer.
USB connection
USB printer
DL6000/
DLM6000
Note
• Connect to the printer directly, not through a hub.
• Only connect a compatible USB keyboard, mouse, printer, or storage device to a USB port for peripherals.
• Do not connect multiple printers to the USB ports for peripherals.
• Never turn off the printer or remove the USB cable while printing is in progress.
• Do not connect or remove USB cables from the time when the DL6000/DLM6000 is turned on until key
operation becomes available (approximately 20 to 30 seconds).
Color (Color)
You can select one of the following options.
ON: The DL6000/DLM6000 prints using the same colors as the screen, excluding the background
color. The grid and some other items are printed in black.
OFF: The DL6000/DLM6000 prints in the same way that it prints from the built-in printer
.
Notes about Printing Using a USB Printer
• Screen captures may not be printed properly on some printers. Use a USB printer that has been
tested for compatibility.
• Y
ou can also print from a USB printer that is connected to a PC. You can save a screen capture to a
storage medium by following the procedure in section 13.6, load the screen capture onto a PC, and
then print it.
Note
• The DL6000/DLM6000 may not detect when a USB printer has run out of paper or has encountered an
error. If an error occurs, press PRINT again to stop printing.
12.3 Printing Using a USB Printer
To Next Page
