YOKOGAWA DL6000 Series User Manual

13-12
IM DLM6054-01EN
FFT
You can save up to 250 Kpoints of data in CSV format.
Data Size
Data size in bytes = The number of data points × 15
Output Example
Analysis Type FFT
Model Name DLM6000
Model Version *.**
Data Points 1251
HResolution 5.00E+02
HUnit Hz
-3.10E+01
-5.43E+01
-4.16E+01
-6.69E+01
-4.80E+01
-5.26E+01
-6.39E+01
-5.11E+01
-5.17E+01
-5.87E+01
Data to Save (Source)
You can save the data from Analysis 1 or 2.
Power Supply Analysis Results (Harmonics)
On models with the power supply analysis option, you can save power supply analysis results in CSV
format. For details, see the separate user’s manual, IM DLM6054-61EN.
Automated Measurements of Waveform Parameters (Wave
Parameter)
You can save automated measurements of waveform parameters in CSV format. The maximum
number of previous values that you can save is equal to 100000/the number of items that are turned
on.
Data Size
Data size in bytes = The number of measured items × 15 × the number of history waveforms
Output Example
Analysis Type WaveParameter
Model Name
DLM6000
Model Version *.**
Rms(C1) Mean(C1) Sdev(C1) ITY(C1) CRms(C1) CMean(C1) CSdev(C1) Dly(C1) Calc1(A2)
V V V Vs V V Vs
:Max 7.12E-01 5.05E-03 7.12E-01 5.05E-05 7.12E-01 5.33E-03 7.12E-01 1.13E-03 1.13E+00
:Min 7.10E-01 -4.44E-03 7.10E-01 -4.44E-05 7.10E-01 -4.46E-03 7.10E-01 -8.99E-04 1.08E+00
:Mean 7.11E-01 1.07E-03 7.11E-01 1.07E-05 7.11E-01 1.05E-03 7.11E-01 3.44E-04 1.10E+00
:Sigma 2.47E-04 2.04E-03 2.48E-04 2.04E-05 3.42E-04 2.11E-03 3.42E-04 9.68E-04 8.23E-03
:Cnt 134 134 134 134 134 134 134 134 134
7021 7.11E-01 2.29E-03 7.11E-01 2.29E-05 7.12E-01 2.33E-03 7.12E-01 1.11E-03 1.10E+00
7031 7.11E-01 1.43E-03 7.11E-01 1.43E-05 7.11E-01 1.41E-03 7.11E-01 1.11E-03 1.11E+00
7040 7.11E-01 3.51E-03 7.11E-01 3.51E-05 7.11E-01 3.01E-03 7.11E-01 1.11E-03 1.10E+00
7050 7.11E-01 1.73E-03 7.11E-01 1.73E-05 7.12E-01 1.86E-03 7.12E-01 1.11E-03 1.11E+00
7059 7.11E-01 1.80E-03 7.11E-01 1.80E-05 7.11E-01 1.99E-03 7.11E-01 -8.86E-04 1.11E+00
7069 7.11E-01 1.15E-03 7.11E-01 1.15E-05 7.11E-01 1.13E-03 7.11E-01 1.11E-03 1.10E+00
7078 7.11E-01 1.45E-04 7.11E-01 1.45E-06 7.11E-01 -1.77E-04 7.11E-01 -8.82E-04 1.12E+00
7088 7.11E-01 2.98E-03 7.11E-01 2.98E-05 7.11E-01 3.18E-03 7.11E-01 1.11E-03 1.10E+00
7098 7.11E-01 3.27E-03 7.11E-01 3.27E-05 7.10E-01 3.69E-03 7.10E-01 -8.92E-04 1.09E+00
7107 7.11E-01 3.12E-03 7.11E-01 3.12E-05 7.11E-01 2.92E-03 7.11E-01 -8.83E-04 1.12E+00
13.6 Saving Other Types of Data
