YOKOGAWA DL6000 Series User Manual

Making Preparations for Measurements
3-15
IM DLM6054-01EN
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Index
App
Logic Input Specifications When Used on the DLM6000
Item When using the 701981 When using the 701980
Maximum toggle frequency
1
250 MHz 100 MHz
Number of inputs 32 (when using four logic probes) Same as the 701981
Non-destructive input voltage
range
2
±40 V(DC + ACpeak) or 28 Vrms
Same as the 701981
Input range ±10 V ±40 V
Maximum sample rate
2.5 GS/s (interleave mode off)
5 GS/s (interleave mode on)
Same as the 701981
Threshold level ±10 V (resolution: 0.1 V) ±40 V (resolution: 0.1 V)
Threshold accuracy
1
±(100 mV + 3% of setting) Same as the 701981
Minimum input voltage
1
500 mVp-p Same as the 701981
Input impedance
(typical value)
3
Approx. 10 k
Ω
, approx. 9 pF Approx. 1 M
Ω
, approx. 10 pF
Preset threshold value CMOS (5 V) = 2.5 V, CMOS (3.3 V) = 1.6 V,
CMOS (2.5 V) = 1.2 V, CMOS (1.8 V) = 0.9 V,
ECL = –1.3 V
Same as 701981
1 Under standard operating conditions (see section 18.11) after a 30-minute warm-up.
2 For information about derating based on frequency for a particular logic probe, see the probe’s user’s manual.
3 Typical value represents a typical or average value. It is not strictly warranted.
Item When using the 701989 When using the 701988
Maximum toggle frequency
1
250 MHz 100 MHz
Number of inputs 32 (when using four logic probes) Same as 701989
Non-destructive input voltage
range
2
±40 V(DC + ACpeak) or 28 Vrms
±42 V(DC + ACpeak) or 29 Vrms
Input range ± 6 V (from the threshold level) ±40 V
Maximum sample rate
2.5 GS/s (interleave mode off)
5 GS/s (interleave mode on)
Same as 701989
Threshold level ±6 V (resolution: 0.1 V) ±40 V (resolution: 0.1 V)
Threshold accuracy
1
±(100 mV + 3% of setting) Same as 701989
Minimum input voltage
1
300 mVp-p 500 mVp-p
Input impedance
(typical value)
3
Approx. 100 k
Ω
, approx. 3 pF Approx. 1 M
Ω
, approx. 10 pF
Preset threshold value CMOS (5 V) = 2.5 V, CMOS (3.3 V) = 1.6 V,
CMOS (2.5 V) = 1.2 V, CMOS (1.8 V) = 0.9 V,
ECL = –1.3 V
Same as 701989
1 Under standard operating conditions (see section 18.11) after a 30-minute warm-up.
2 For information about derating based on frequency for a particular logic probe, see the probe’s user’s manual.
3 Typical value represents a typical or average value. It is not strictly warranted.
Connection Procedure
For instructions on how to connect a particular logic probe, see its user’s manual.
Make sure to turn off the power to the DLM6000 before connecting or disconnecting a logic probe
cable.
Note
If the logic probe is not connected to the DLM6000, the logic probe input is at low level.
3.6 Connecting Logic Probes
