YOKOGAWA DLM4000 Series User Manual

2-19
IM DLM4038-02EN
ID OR Mode (ID OR)
Setting Trigger Conditions (Condition Setup)
Press the Mode soft key, the ID OR soft key, and then the Condition Setup soft key to display the
following screen.
The DLM4000 triggers when the condition of one of the four IDs is met. Items whose check boxes
are selected are used as trigger conditions.
Set the ID comparison condition.
Set the Cycle Count comparison
condition.
Set data reference values a and b.
Set data reference values a and b.
Select Don’t Care if you do not
want to make the cycle count a
trigger condition for ID2.
Select an ID’s check box to use it as a trigger condition.
2.9 Triggering on FlexRay Bus Signals (Option)
