YOKOGAWA DLM4000 Series User Manual

2-35
IM DLM4038-02EN
Setting the Trigger Source (Source)
Press the Source soft key to display one of the menus shown below. The menu that is displayed
varies depending on the specified trigger source.
When the Trigger Source Is a Channel from CH1 to CH8
Set the trigger source (CH1 to CH8).
Set the trigger coupling, HF rejection, and
noise rejection.
► section 2.3
Set the level used to detect source states.
When the Trigger Source Is LOGIC(L) or LOGIC(A|B)
Set the trigger source (LOGIC(L) or LOGIC(A
|
B)).
*
Set the source bit (L0 to L7, A0 to A7, B0 to B7).
*
Set the level used to detect source states.
* You can select CH8 or LOGIC(L), depending on which channel’s corresponding key (CH8 or L) is
illuminated.
LOGIC(A|B), A0 to A7, and B0 to B7 are available on models with the /L16 option.
2.13 Triggering on SENT Signals (Option)
