YOKOGAWA DLM4000 Series User Manual

2-43
IM DLM4038-02EN
Setting the Sync Signal (Sync)
Press the Sync soft key to display the following menu.
Set the sync signal (CH1 to CH8, X).
Set the level used to detect the
state of the sync signal.
Set the trigger coupling, HF rejection,
and noise rejection.
►section 2.3
* If you select X, sync signal will not be detected.
Therefore, Trigger mode Sync will not be
available.
Setting the Data Frame Source (Data)
Press the Data soft key to display the following menu.
Set the data frame source (CH1 to CH8).
Set the data length (10bit, 16bit).
Set the error detection method (Parity, CRC).
Set the trigger coupling, HF rejection, and
noise rejection.
►section 2.3
Set the bit rate (125kbps, 189kbps,
User Define).
Set the bit rate.
Set the level used to detect
data frame source states.
When the bit rate is set
to User Define
Set the level used to detect data
frame source states.
2.14 Triggering on PSI5 Airbag Signals (Option)
