CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
TROUBLESHOOTING
1.2 ERROR MESSAGES
1 - 4
1
Search
Book TOC
Go Back
Alarm 4 (b) X Ori
in and Limit Sensors BOTH ON at Power On. IP - 8
(X Transport Home and Limit Sensors both active durin
initialization of Sample Loader.)
Alarm 4 (c) Mixin
Paddle’s Ori
in and Position Sensors BOTH ON at Power
On.
IP - 9
Alarm 4 (d) Mixin
Paddle’s Ori
in and Limit Sensors BOTH ON at Power On. IP - 10
Alarm 4 (e) X Home Sensor Failure. IP - 11
Time-out in an attempt to drive X-axis mechanism to/from its ori
in.
A test performed durin
initialization and Run where the particular
mechanism is moved sli
htly past a particular sensor then back
and forth several times. The Sensor operation is verified each
time.
Alarm 4 (f) Y Home Sensor Failure. IP - 12
Time-out in an attempt to drive Y-axis mechanism to/from its ori
in.
A test performed durin
initialization and Run where the particular
mechanism is moved sli
htly past a particular sensor then back
and forth several times. The Sensor operation is verified each
time.
Table 1 - 1 Error Messages(continued)
MESSAGE
CORREC-
TIVE
ACTION
